Product Code :

CSD150

Operating Voltage :

230 V AC ± %10 50 Hz

Motor Voltage :

24 V DC

Opening Speed (Adjustable) :

0.9 m/s

Closing Speed (Adjustable) :

0.7 m/s

Max. Leaf Weight :

75 kg (1 leaf), 150 kg (2 leaves)

Kit Dimensions & Weight :

50 x 30 x 15 cm / 11 kg

Failure Reporting :

Led display on main board

Engine Lock :

Available

Self Positioning :

Available

Extra Photocell :

Optional

Extra Radar :

Optional

Opening-Closing with Remote Controller :

Optional

Hand Sensor :

Optional

Thumbwheel Switch & RF Card Reader :

Optional

Permanent Open-Permanent Close :

Available

Language Features :

English, Turkish

Current Draw :

0,6 A

Motor Power :

95 W

Staying Open Duration :

3 & 5 seconds (two-stage with switch)

Protection Level :

IP 20 only for dry environments

Operating Temperatures :

Between -15° and 60°C

Aluminium Chassis Dimensions :

3.5 / 4.5 / 6.5 meter

Adjustable Staying Open Duration :

Two-stage with switch

Adjustable Speed :

Available

Photocell :

Available

Height Photocell :

Optional

Curtain Photocell Microwave Radar :

Optional

Bluetooth Technology :

Optional

Bend Button :

Optional

ID Card Transition :

Optional

Only Input-Only Output :

Available

Half Opening :

Automatically adjustable

Opti. accessory, compat. with Bluetooth, Android and Apple systems
